Fresh Air Ventilation Smart HVAC Controller With Eco Mode Reduced Energy Consumption

Name: Fresh Air Ventilation Smart HVAC Controller With Eco Mode Reduced Energy Consumption
Brand: OEM or neutral (no brand)
Price: 103 USD

Wholesale Fresh Air Ventilation Smart HVAC Controller With Eco Mode Reduced Energy Consumption from china suppliers

Feature : Flexible, Energy Saving, Easy Install

Shell color : White

Model Number : G7 Pro

Delivery Time : 2-3 weeks

Place of Origin : China

Suitable for fans : AC/EC/DC fans

Supply Ability : 100000pcs

Warranty : 1 Year

Material : PC and ABS

MOQ : 1

Certification : CE, RoHS

Payment Terms : T/T

Price : $103

Brand Name : OEM or neutral (no brand)

Optional built in sensors : VOC+PM2.5+CO2+Temperature+Humidity

Contact Now

G7 PRO -- Smart HVAC Controller engineered for performance easy installation and integration with existing building automation platforms

Product Overview

G7 Pro (black UI version) is an intelligent fresh air ventilation controller that integrates multiple sensors including PM2.5, CO2, VOC temperature, and humidity. The device features a 7-inch HD color screen with high-sensitivity touch screen design.

Equipped with Wi-Fi for remote access and control via the internet, it also includes RS485 port and MODBUS protocol for communication with smart home and building automation systems.

The AC version outputs relay signals to directly control AC fan start, stop, and speed regulation, while the DC version outputs separate control voltages for DC fan operation. Suitable for residential, commercial, and industrial applications, it effectively improves air quality and creates healthy, comfortable, efficient, and energy-saving environments.

Key Features

Temperature & Humidity Monitoring
CO₂, PM2.5, VOC Sensors Data Based Ventilation Control
Reduced HVAC Energy Consumption
Automatic Energy Optimization
Energy Recovery Ventilation (ERV) Compatible
Heat Recovery Ventilation (HRV) Compatible

Product Specifications

Dimension	115 × 185 mm
Display Interface	7 inch, 1024 x 600
Warm-up Time	2 minutes
Response Time	≤ 10 seconds
Wiring Terminal	Max 2.5 mm² wire
Recovery Time	≤ 30 seconds
Rated Voltage	AC110-240V, 50/60Hz
Operating Temperature	-10℃ to +50℃
Standby Power	≤ 3.0W
Operating Humidity	5％RH to 90％RH
Control Power	≤ 200W
Storage Temperature	-10℃ to +60℃
Suitable for Fans	AC/EC/DC
PM2.5 Display Range	0μg/m³ to 999μg/m³
Temperature Display Range	0℃ to 99℃
CO2 Display Range	0ppm to 9999ppm
Humidity Display Range	0% to 99%
Fixing Hole Distance	60mm (standard)
